FR1 Coppr clad laminate
Type: FR1
FR1 copper clad laminate sheet consist of bleached wood pulp paper, impregnated with flame resistant phenolic resin and clad with electrolytic copper foil. With high electrical stability, good flame retardancy, good dimension stability and good punching ability, widely used for Hi-Fi acoustic devices, color TV sets and other electronic appliances.
Thickness: 0.4-3.2 mm
Copper: 18/0, 25/0, 35/0
other thickness according to negotiation
Size: 1020x1220mm, 914x1220mm, 1067x1220mm |
|
