Phenolic cotton laminated sheet
Type: 3025A, 3025B, 3026, 3027 (China standard)
C, CE, L, LE (NEMA standard)
Made from cotton cloth that impregnated with phenolic resin under pressure and heat. With high mechanical strength and electrical properties, it is used for the insulating spare parts of electrical appliances and transformers, textile machines, gears, fixed frames for bearings and noise reduction. Thermal grade is class E.
Thickness : 0.5-100mm;
Width x length: 1020x1220mm, 980x1980mm, 1000x2000mm, 1220x2440mm
Technical data sheet available |
|
