VPI Mica tape
OM201: Glass cloth/Mica
OM202: PET(polyester, Mylar) film/Mica
OM203: PET(polyester, Mylar) film/Mica/Glass cloth
OM204: Polyimide(Kapton) film/ Mica
VPI Mica tape is a kind of dry Micapaper tape, supported by Glass cloth, PET film or polyimide film and impregnated with high-property resin, compatible with epoxy system and unsaturated polyester system, it shows excellent electrical, mechanical properties, good integrity with long-operating life after coils wrapped and VPI treatment, widely used for VPI insulation in F-class DC and traction machines.
Thickness: 0.10-0.16 mm
Width: 6-6- mm Length: 1-20 m |
|
